2MP Bullet Thermal Camera Infrared thermal Imager Scanner with Software Waterproof IP67 ( T30 PRO)
Model: T30 PRO
Brand: GRANDING
Product Description:
T30 PRO 2MP Thermal temperature measurement binocular bullet camera, based on Hisilicon embedded coding platform, integrated thermal imaging and visible light image sensors for temperature measurement. The maximum output resolution of the visible light sensor is 1920x1080@30fps, with High accuracy. This product can support the advanced h. 265 Main profile encoding technology, achieve lower bit rate, HD picture quality. Support ONVIF,GB/T28181 etc. Network protocol, Standard SDK is available for quick integration. It can be widely used in close-range scene monitoring.
1. Thermal imaging detector pixels 256x192
2. 1/2.8" 2.0M CMOS Sensor
3. Maximum resolution 1920x1080@30fps
4. Embedded deep learning algorithms, Support face snapshot function, can detect and capture 20 to 30 faces at the same time
5. Support face tracking and scoring, More frames to identify, Automatic filtering output optimal face, and reduce repetitive capture
6. Support H.265+ / H.265/ H.264 + MJPEG dual stream, three stream
7. Support ONVIF, GB/T28181, etc. network protocol
| Thermal Module | |
| Sensor | Silicon oxide uncooled focal plane detector |
| Resolution | 256X192 |
| Size | 12μm |
| NETD | ≤60mk @25ºC,F#=1.0 |
| Temperature Accuracy | Target Temperature 35ºC~38ºC; Temperature Accuracy±0.3ºC Target Temperature 20ºC~33ºC or 38ºC~50ºC: Temperature Accuracy ±0.6ºC |
| FOV | Horizontal:35° Vertical:27° |
| Image Mode | white heat, black heat, fusion, rainbow, iron red, and other false colors |
| Visible Light | |
| Sensor | 1/2.8"2.0M Pixel CMOS |
| Illumination | 0.005Lux@F1.2(Color),0.001Lux@F1.2(B/W) |
| WDR | ≥80dB |
| S/N Ratio | ≥46dB(AGC OFF) |
| Focus | 4mm |
| FOV | Horizontal 84°, Vertical45° |
| AI | |
| Face Capture | Embedded deep learning algorithms, Support face snapshot function, can detect and capture 20 to 30 faces at the same time. Support face tracking and scoring, More frames to identify, Automatic filtering output optimal face, And reduce repetitive capture. Support ONVIF,GB/T28181 etc. Network protocol. |
| Function | |
| Measurement | Support global and regional temperature measurement |
| Alarm | High-temperature limit/low-temperature limit/area temperature difference alarm |
| Protocol | Support RTSP,RTP,TCP,UDP,UPNP,DHCP,PPPoE,ONVIF,GB/T 28181 protocol |
| Network Interface | 1CH 10/100BaseT Ethernet, RJ45 port |
| Alarm Interface | Reserved |
| Voice Interface | Reserved |
| General | |
| Operating Temps | -20ºC~55ºC |
| Operating Humidity | 0%-90% RH(Non-condensing) |
| Protection class | IP67 |
| Power Supply | 12VDC |
| Consumption | ≤5W(without heating) |
| Size | 246mm*101mm*81mm |
| Weight | <1kg |
